Description
General
- Classes:Class 3 (E-bikes can go up to 45 km/s with pedal assistance)
- Max Speed: 45 Km/h by pedal, 40 Km/h by throttle
- Range:up to 120 Km by Pedal; 45 Km by Throttle(Calculation based on rider’s weight of 75kg. Range varies according to road condition, weather, rider’s weight etc.)
- Pedal Assist:5 Levels
Frameset
- Frame: 6061 Aluminium, Removable Battery, Internal Routing
- Fork:Hydraulic Suspension Fork with 60mm travel, with lockout
Wheels
- Rim Material:Aluminum
- Rim Size: 26″ 36H Front & Rear
- Front Wheel Spokes:13G x 244/246mm, Black Stainless
- Rear Wheel Spokes:12G x 217/219mm, Black Stainless
- Tubes: Butyl Rubber, Schrader Valve
- Hubs:Disc Nutted Front /Rear Axles
- Tire: Kenda Fat Tires
- Tire Size: 26″ x 4.0″
E-system
- Battery:Removable Internal Lithium-ion Battery, 48V 15Ah, 720Wh, LG Cells
- Charger:48V 2 Amp Charger, Approx. 8 Hour Charging, Aviation Connector. UL LISTED
- Motor:Geared Hub Motor, Rated 750W, Peak 1000W, Max Torque 80NM
- Controller: 48V 25A Peak
- Display: Multifunctional Color-Screen Display
- Pedal Assist: Cadence Sensor
- Throttle: Thumb Throttle
- Front Light:48V 10W LED Light, 30 LUX
Drivetrain
- Shifter: Shimano 7-Speed Revo Shift
- Rear Derailleur: Shimano ARDTY500D 7-Speed, Long Cage
- Crank & Chainring: 52T, 170mm Alloy Crank
- Freewheel: Shimano 14-28T, 7-Speed freewheel
- Pedal: Alloy Platform Pedals
- Chain: KMC 124 Link, 7-Speed
Components
- Saddle: Comfortable Wide Saddle
- Seatpost:Forged Alloy, Ø30.4*350mm
- Seat Clamp:Ø35mm Quick Release
- Stem:Bar bore: Ø31.8mm, Clamp I.D.: Ø28.6mm, HEIGHT: 70mm, RISE: ±7°
- Handlebar:Aluminum Ø31.8mm, Width 740mm
- Headset:Sealed Bearing Headset
- Grips:Nylon Lock-on, Ergonomic Comfort
- Brake:Front & Rear Hydralic Disc Brakes, with180mm discs, with power-cut-off function
- Brake rotor: 180mm, 1.9mm thick
- Kickstand:Side Kickstand, Alloy, Rear Mount
- Fenders:Plastic 26″x110mm
- Rear Rack:Aluminum Alloy Rear Rack
Weight
- Net Weight:33.1kg (72.97lb) ( including battery)
- Gross Weight:43.8kg (96.56lb)
- Battery Weight:4kg (8.82lb)
- Weight limit:136 kg (300 lb) Payload Capacity
Size
- Product Size:1930x755x1110mm
- Packing Size:1570x330x900mm
